Camera
Image Sensor 1/3″ Progressive Scan CMOS
Min. Illumination Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
Wide Dynamic Range 120dB
Day & NightI CR Cut
Linkage Method Upload to FTP, notify surveillance center, send email, trigger capture
Angle Adjustment P an: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°
Lens
Lens Type & FOV 4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 88°; 6 mm, horizontal FOV 49°, vertical FOV 26°, diagonal FOV 57°
Aperture 4 mm F2.0; 6mm F1.6
Lens Mount M12
Illuminator
IR Range 50 m
Wavelength 850nm
Smart Supplement Light Yes
Smart IR Yes
Day/Night Switch Day, Night, Auto, Schedule
Image Enhancement BLC, HLC, 3D DNR
Image Settings Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
SNR ≥ 52 dB
Interface
Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
Intelligent (Traditional Algorithm)
Basic Event Motion detection, video tampering alarm
General
Firmware Version V5.5.84
Web Client Language English, Russian, Italian, French, Polish, Spanish, Turkish, Portuguese
General Function Anti-flicker, heartbeat, mirror, password protection, privacy masks, watermark, IP address filter
Software Reset Yes
Material Front cover & bracket: metal; back cover & sun shield: plastic
Camera Dimension 71.67 × 92.87 × 221.49 mm (2.82" × 3.65" × 8.72")
Package Dimension 234 × 120 × 117 mm (9.21″ × 4.72″ × 4.61″)
Camera Weight 500 g (1.10 lb.)
With Package Weight 670 g (1.48 lb.)
Approval
Protection ngress protection: IP67 (IEC 60529-2013)
EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); IC (ICES-003: Issue 6, 2016)
Safety UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
